MCX ISOLATORS
SWITCH-DISCONNECTOR AEG MCXT7 3P 1600A
MCXT7D31600
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC / 750 DC
Rated insulation voltage Ui (V)
1000
Short time current Icw x 1s (kA)
20
Conventional thermal current Ith (A)
1600
Short circuit making current capacity Icm
40(only disconnector) / 252(with circuit-breaker) kA
Rated current in category AC-22A (A) at 400/500/690V
1600/1600/1600
Rated current in category AC-23A (A) at 400/500/690V
1600/1600/1600
Rated current in category DC-22A
1600A at 750V (4p in series)
Mechanical life
20.000 operations
Electrical Life at In
2500 operations
Power loss
282 W
Standard connection terminals
50x20 mm²
Torque
18 Nm
Approvals
CE
State
On sale
