MCX ISOLATORS
SWITCH-DISCONNECTOR AEG MCXT5 4P 400A
MCXT5D4400
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Number of Poles
4
Rated Operational Voltage Ue (V)
690 AC / 750 DC
Rated insulation voltage Ui (V)
1000
Short time current Icw x 1s (kA)
5
Conventional thermal current Ith (A)
400
Short circuit making current capacity Icm
7,65(only disconnector) / 440(with circuit-breaker) kA
Rated current in category AC-22A (A) at 400/500/690V
400/400/400
Rated current in category AC-23A (A) at 400/500/690V
400/400/400
Rated current in category DC-22A
400A at 250-500V (2p series); 400A/750V (3p series)
Mechanical life
20.000 operations
Electrical Life at In
5000 operations
Power loss
72,3 W
Standard connection terminals
32,5x10 mm²
Torque
36 Nm
Approvals
CE
State
On sale
