MCX ISOLATORS
SWITCH-DISCONNECTOR AEG MCXT3 3P 250A
MCXT3D3250
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC / 500 DC
Rated insulation voltage Ui (V)
800
Short time current Icw x 1s (kA)
3
Conventional thermal current Ith (A)
250
Short circuit making current capacity Icm
5,3(only disconnector) / 105(with circuit-breaker) kA
Rated current in category AC-22A (A) at 400/500/690V
250/250/250
Rated current in category AC-23A (A) at 400/500/690V
200/200/200
Rated current in category DC-22A
250A/250V (2p series) ; 250A/500V (4p series)
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Power loss
53,4 W
Standard connection terminals
24x8 mm²
Torque
8 Nm
Approvals
CE
State
On sale
