MCX ISOLATORS
SWITCH-DISCONNECTOR AEG MCXT1 3P 160A
MCXT1D3160
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC / 500 DC
Rated insulation voltage Ui (V)
800
Short time current Icw x 1s (kA)
2
Conventional thermal current Ith (A)
160
Short circuit making current capacity Icm
2,8(only disconnector) / 154(with circuit-breaker) kA
Rated current in category AC-22A (A) at 400/500/690V
160/160/160
Rated current in category AC-23A (A) at 400/500/690V
125/125/125
Rated current in category DC-22A
160A/250V (2p series) ; 160A/500V (4p series)
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Power loss
45 W
Standard connection terminals
16x5 mm²
Torque
3 Nm
Approvals
CE
State
On sale
