MCBs series DG60+
MCB AEG DG+ 2P 40A 6kA 2M
DG62C40
DG60+ INTERRUTTORI MODULARI CON PROTEZIONE PER SOVRACCARICO E PER CORTOCIRCUITO. SONO DISPONIBILI IN VERSIONE 1P+N E 2P, CON CARATTERISTICA DI INTERVENTO IN CURVA C, CORRENTE NOMINALE DA 6A A 40A, CON POTERE DI INTERRUZIONE 6KA. TUTTI GLI INTERRUTTORI SERIE DG60+ SONO CONFORMI ALLA NORMA EN60898 PER APPLICAZIONI DOMESTICHE
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
40 A
Number of Poles
2
Rated Breaking Capacity
6 kA
Characteristic
C (5 - 10 In)
Standard
EN 60898
Short circuit capacity EN60947-2 Icu at 400V
-- kA
Number of modules
2
Power loss
9,6 W
Rated Voltage AC
400 V
Min-Max operating voltage AC
12/440 V
Frequency
50/60 Hz
Protection degree
IP40 HOUSING (IP20 terminals)
Current limitation class
3
Standard connection terminals
25 top bottom mm²
Torque
2 Nm
Working temperature
-25/+55 °C
Storage temperature
-40/+70 °C
Mechanical life
20000 operations CO
Mounting
any
Approvals
CE, AENOR
State
On sale
Brand
AEG
