MCB AEG DG+ 2P 25A 4,5KA 2M

DG42C25

+

Rated Current (A)

25 A

Number of Poles

2

Rated Breaking Capacity

4,5 kA

Characteristic

C (5 - 10 In)

Standard

EN 60898

Short circuit capacity EN60947-2 Icu at 400V

-- kA

Number of modules

2

Power loss

6,4 W

Rated Voltage AC

230/400 V

Min-Max operating voltage AC

12/440 V

Frequency

50/60 Hz

Protection degree

IP40 HOUSING (IP20 terminals)

Current limitation class

3

Standard connection terminals

25 top bottom mm²

Torque

2 Nm

Working temperature

-25/+55 °C

Storage temperature

-40/+70 °C

Mechanical life

20000 operations CO

Mounting

any

Approvals

IMQ

State

On sale

Brand

AEG
