MCB AEG DCC+ 1+N 25A 4,5KA 1M
DCC41NC25
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
25 A
Number of Poles
1+N
Rated Breaking Capacity
4,5 kA
Characteristic
C (5 - 10 In)
Standard
EN60947-2, EN60898
Short circuit capacity EN60947-2 Icu at 400V
6 kA
Number of modules
1
Power loss
4,40 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
12-254 V
Frequency
50/60 Hz
Protection degree
IP40 HOUSING (IP20 terminals)
Current limitation class
3
Standard connection terminals
stranded/solid 10/16 mm²
Torque
1,2 Nm
Working temperature
-25/+55 °C
Storage temperature
-40/+70 °C
Mechanical life
20000 operations CO
Mounting
any
Approvals
IMQ
State
On sale
Brand
AEG
