MCB AEG DCC+ 1+N 10A 4,5KA 1M

DCC41NC10

+

Rated Current (A)

10 A

Number of Poles

1+N

Rated Breaking Capacity

4,5 kA

Characteristic

C (5 - 10 In)

Standard

EN60947-2, EN60898

Short circuit capacity EN60947-2 Icu at 400V

6 kA

Number of modules

1

Power loss

1,9 W

Rated Voltage AC

230 V

Min-Max operating voltage AC

12-254 V

Frequency

50/60 Hz

Protection degree

IP40 HOUSING (IP20 terminals)

Current limitation class

3

Standard connection terminals

stranded/solid 10/16 mm²

Torque

1,2 Nm

Working temperature

-25/+55 °C

Storage temperature

-40/+70 °C

Mechanical life

20000 operations CO

Mounting

any

Approvals

IMQ

State

On sale

Brand

AEG
