Manual changeover switches 2-layers CSHLNS
TWO LAYERS MANUAL CHANGEOVER SWITCH HLN5S 4P 800A
CSHLN5S4800
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
800 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1500
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
800/800/800
Rated current in category AC-22A (A) at 400/500/690V
800/800/800
Rated current in category AC-23A (A) at 400/500/690V
800/500/400
Rated closing/breaking current at 400V AC23 (A)
6300/5040
Short time current Icw x 1s (kA)
26,5
Short time current Icw x 0,25s (kA)
30
Rated fuse short circuit current (kA)
50 (fuse 800A)
Mechanical life
8000 operations
Electrical Life at In
1500 operations
Power Loss for each pole (W)
25,7
Standard connection terminals
2x240 mm²
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
Brand
SCHALT
