Manual changeover switches 2-layers CSHLNS
TWO LAYERS MANUAL CHANGEOVER SWITCH HLN4S 4P 400A
CSHLN4S4400
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
400 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1500
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
400/400/400
Rated current in category AC-22A (A) at 400/500/690V
400/400/400
Rated current in category AC-23A (A) at 400/500/690V
400/315/250
Rated closing/breaking current at 400V AC23 (A)
4000/3200
Short time current Icw x 1s (kA)
13
Short time current Icw x 0,25s (kA)
26
Rated fuse short circuit current (kA)
50 (fuse 400A)
Mechanical life
8000 operations
Electrical Life at In
1500 operations
Power Loss for each pole (W)
9,4
Standard connection terminals
240 mm²
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
Brand
SCHALT
