Interface switchboards CEI 0-21
QUADRO INTERFACCIA PER IMPIANTO 20KW CEI 0-21 3F+N
PVQI20-OPEN
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Operational Voltage Ue (V)
400 AC
Rated Power
20 kW
Protection main switch
E94SC40
Ultimate breaking capacity Icu at 400 V AC
15 kA
Number of poles main switch
4
Main switch rated current
40 A
Type of over voltage protection device
Type 2
Mounting method
Surface mounted
Housing material
Plastic
Protection degree
IP54
Height
600 mm
Width
400 mm
Depth
200 mm
Colour
Grey
RAL-number
7035
Net Weight
13 kg
Standard
CEI0-21, EN61439-1, EN61439-2
Brand
ELETTRA
Megiston
