Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN7S 3P 2000A
HLN7S32000
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 2000A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3, Potenza dissipata 183,9W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
2000 A
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
2000/1600/1250
Rated current in category AC-22A (A) at 400/500/690V
1250/-/-
Rated current in category AC-23A (A) at 400/500/690V
-/-/-
Rated power in AC23 (kW) at 415/500/690V
630
Rated closing/breaking current at 400V AC23 (A)
--
Short time current Icw x 1s (kA)
50
Short time current Icw x 0,25s (kA)
100
Rated fuse short circuit current (kA)
--
Short circuit making current capacity Icm
105 kA
Power loss
183,9 W
Mechanical life
4000 operations
Electrical Life at In
500 operations
Standard connection terminals
3x50x12 mm²
Width
361 mm
Height
306 mm
Depth
186 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
