Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN6S 4P 1000A
HLN6S41000
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
1000 A
Number of Poles
3+N
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-22A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-23A (A) at 400/500/690V
1000/800/400
Rated power in AC23 (kW) at 415/500/690V
525
Rated closing/breaking current at 400V AC23 (A)
10000/8000
Short time current Icw x 1s (kA)
35
Short time current Icw x 0,25s (kA)
70
Rated fuse short circuit current (kA)
100 (fuse 1000A)
Short circuit making current capacity Icm
73,5 kA
Power loss
81,9 W
Mechanical life
7000 operations
Electrical Life at In
1.000 operations
Standard connection terminals
2x50x6 mm²
Width
356 mm
Height
306 mm
Depth
147 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
