Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN6S 3P 1000A
HLN6S31000
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 1000A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3, Potenza dissipata 81,9W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
1000 A
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-22A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-23A (A) at 400/500/690V
1000/800/400
Rated power in AC23 (kW) at 415/500/690V
525
Rated closing/breaking current at 400V AC23 (A)
10000/8000
Short time current Icw x 1s (kA)
35
Short time current Icw x 0,25s (kA)
70
Rated fuse short circuit current (kA)
100 (fuse 1000A)
Short circuit making current capacity Icm
73,5 kA
Power loss
81,9 W
Mechanical life
7000 operations
Electrical Life at In
1.000 operations
Standard connection terminals
2x50x6 mm²
Width
356 mm
Height
306 mm
Depth
147 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
