Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN5S 3P 630A
HLN5S3630
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 630A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3, Potenza dissipata 46,8W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
630 A
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
630/630/630
Rated current in category AC-22A (A) at 400/500/690V
630/630/630
Rated current in category AC-23A (A) at 400/500/690V
630/500/400
Rated power in AC23 (kW) at 415/500/690V
330
Rated closing/breaking current at 400V AC23 (A)
6300/5040
Short time current Icw x 1s (kA)
26,5
Short time current Icw x 0,25s (kA)
53
Rated fuse short circuit current (kA)
50 (fuse 630A)
Short circuit making current capacity Icm
30 kA
Power loss
46,8 W
Mechanical life
8000 operations
Electrical Life at In
1.500
Standard connection terminals
2x40x5 mm²
Width
280 mm
Height
230 mm
Depth
120,5 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
