Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN4S 4P 500A
HLN4S4500
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
500 A
Number of Poles
3+N
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
400/400/400
Rated current in category AC-22A (A) at 400/500/690V
500/400/400
Rated current in category AC-23A (A) at 400/500/690V
500/315/250
Rated power in AC23 (kW) at 415/500/690V
210
Rated closing/breaking current at 400V AC23 (A)
4000/3200
Short time current Icw x 1s (kA)
13
Short time current Icw x 0,25s (kA)
26
Rated fuse short circuit current (kA)
50 (fuse 500A)
Short circuit making current capacity Icm
26 kA
Power loss
44,4 W
Mechanical life
8000 operations
Electrical Life at In
1.500
Standard connection terminals
2x25x5 mm²
Width
235 mm
Height
196 mm
Depth
93 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
