Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN4S 3P 400A
HLN4S3400
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 400A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3, Potenza dissipata 28,2W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
400 A
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
400/400/400
Rated current in category AC-22A (A) at 400/500/690V
400/400/400
Rated current in category AC-23A (A) at 400/500/690V
400/315/250
Rated power in AC23 (kW) at 415/500/690V
210
Rated closing/breaking current at 400V AC23 (A)
4000/3200
Short time current Icw x 1s (kA)
13
Short time current Icw x 0,25s (kA)
26
Rated fuse short circuit current (kA)
50 (fuse 400A)
Short circuit making current capacity Icm
26 kA
Power loss
28,2 W
Mechanical life
10000 operations CO
Electrical Life at In
1.500
Standard connection terminals
2x25x5 mm²
Width
235 mm
Height
196 mm
Depth
93 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
