Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN3S 4P 200A
HLN3S4200
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
200 A
Number of Poles
3+N
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
200/200/200
Rated current in category AC-22A (A) at 400/500/690V
200/200/200
Rated current in category AC-23A (A) at 400/500/690V
200/160/125
Rated power in AC23 (kW) at 415/500/690V
105
Rated closing/breaking current at 400V AC23 (A)
2000/1600
Short time current Icw x 1s (kA)
8
Short time current Icw x 0,25s (kA)
16
Rated fuse short circuit current (kA)
50 (fuse 200A)
Short circuit making current capacity Icm
13,5 kA
Power loss
7,2 W
Mechanical life
10000 operations CO
Electrical Life at In
2000 operations CO
Standard connection terminals
95 mm²
Width
168 mm
Height
152 mm
Depth
81 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
