Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN3S 4P 160A
HLN3S4160
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 160A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3+N, Potenza dissipata 13,5W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
160 A
Number of Poles
3+N
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
160/160/160
Rated current in category AC-22A (A) at 400/500/690V
160/160/160
Rated current in category AC-23A (A) at 400/500/690V
160/125/100
Rated power in AC23 (kW) at 415/500/690V
85
Rated closing/breaking current at 400V AC23 (A)
1600/1280
Short time current Icw x 1s (kA)
8
Short time current Icw x 0,25s (kA)
16
Rated fuse short circuit current (kA)
50 (fuse 160A)
Short circuit making current capacity Icm
13,5 kA
Power loss
4,8 W
Mechanical life
10000 operations CO
Electrical Life at In
2000 operations CO
Standard connection terminals
70 mm²
Width
168 mm
Height
152 mm
Depth
81 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
