Industrial switch disconnectors HLNS series
SEZIONATORE SCHALT HLN3S 3P 250A
HLN3S3250
Sezionatore SCHALT modello HLN1HS, Corrente nominale Ie 250A, Tensione nominale di impiego Ue 690V, Tensione di isolamento Ui 1000V, Poli 3, Potenza dissipata 11,4W.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
250 A
Number of Poles
3
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
250/250/250
Rated current in category AC-22A (A) at 400/500/690V
250/250/250
Rated current in category AC-23A (A) at 400/500/690V
250/200/160
Rated power in AC23 (kW) at 415/500/690V
130
Rated closing/breaking current at 400V AC23 (A)
2500/2000
Short time current Icw x 1s (kA)
8
Short time current Icw x 0,25s (kA)
16
Rated fuse short circuit current (kA)
50 (fuse 250A)
Short circuit making current capacity Icm
13,5 kA
Power loss
11,4 W
Mechanical life
10000 operations CO
Electrical Life at In
2000 operations CO
Standard connection terminals
120 mm²
Width
168 mm
Height
152 mm
Depth
81 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
