Impulse switches
IMPULSE SWITCH AEG PLS+ 1NO 16A 230VAC/110VDC
PLSS1610230
RELE' PASSO PASSO AEG PER 16A CON TENSIONE DI COMANDO 230VAC/110VDC O 12VAC, CONTATTI 1NO E 2NO
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
16 A
Control voltage (V)
230AC/110DC
Contacts
1NO
Type
Step relay
Number of modules
1
Rated Operational Voltage Ue (V)
250 AC
Frequency
50/60 Hz
Power loss
0,32 W
Operation temperature (°C)
-25/+55
Storage temperature
-40/+70 °C
Standard connection terminals
2,5 mm²
Torque
1,2 Nm
Electrical Life at In
150.000
Mechanical life
250.000
Consumption at 110V
0,057A
Consumption at 230V
0,062A
Standard
EN 60669-1; EN60669-2-2
Brand
AEG
State
On sale
Megiston
