Energy kWh-Meters
CONTATORE ENERGIA 3F+N TA/333mV MODBUS RS485/ETHERNET
EXW4-4ETH
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
3L+N, 3L, LN
Insertion
CT/333mV
Meausre
V, A, kW, KVAr, kVA, kWh, kVArh, Pf, Hz, Multitariff, Max Demand
Rated Operational Voltage Ue (V)
230/400 AC
Min-Max operating voltage AC
30...300 Vac (L-N), 30...500 Vac (L-L) V
Number of modules
4
Max Current (A)
5
Frequency
45/60 Hz
Consumption
4VA
Technical Feautures
USCITA ETHERNET E RS485
Working temperature
-25/+55 °C
Storage temperature
-40/+80 °C
Class
0,5S
Protection degree
IP51
Standard
IEC61557-12
Approvals
CE
State
On sale
Brand
SCHALT
