Elfa NEXT E88050
INTERRUTTORE AEG SERIE E880+ 2P B 80A 50kA
E880502B80
INTERRUTTORE AUTOMATICO AEG 2P B 80A 50kA
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
80 A
Number of Poles
2
Characteristic
B (3 - 5 In)
Short circuit capacity EN60947-2 at 400V
50 kA
Short circuit capacity according to EN60898-1 Icn
25 a 230/400V kA
Standard
EN60947-2, EN60898
Number of modules
3
Power loss
12,8 W
Rated Voltage AC
240/415 V
Min-Max operating voltage AC
12/440 V
Frequency
50/60 Hz
Rated Voltage DC
250 V
Max operating voltage DC (V)
250
Rated insulation voltage Ui (V)
690
Standard connection terminals
70 mm²
Isolator application according to EN 60947-2
YES
Torque
3,5 Nm
Working temperature
-25/+60 °C
Storage temperature
-40/+70 °C
Calibration Temperature (°C)
30
Mounting
any
State
On sale
Brand
AEG
