Series E90
MCB AEG Elfa E90X 3P C 16A 25kA
E93XC16
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
16 A
Number of Poles
3
Rated Breaking Capacity
25 kA
Characteristic
C (5 - 10 In)
Standard
EN 60947-2
Number of modules
3
Power loss
7,758 W
Rated Voltage AC
415 V
Min-Max operating voltage AC
12-250/440 V
Frequency
50/60 and DC Hz
Rated Voltage DC
110 (2 Poles in Series) V
Short circuit capacity EN60947-2 Icu at 400V
25 kA
Service breaking capacity Ics (%Icu)
50%
Standard connection terminals
1…35 mm²
Isolator application according to EN 60947-2
YES
Working temperature
-25/+55 °C
Storage temperature
-55/+55 °C
Approvals
VDE
Calibration Temperature (°C)
40
Current limitation class
3
Mounting
any (except upside down)
State
On sale
Brand
AEG
