Series E90
MCB AEG Elfa E90E 3P C 25A 4,5kA
E93EC25
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
25 A
Number of Poles
3
Rated Breaking Capacity
4,5 kA
Characteristic
C (5 - 10 In)
Standard
EN 60898
Number of modules
3
Power loss
9,564 W
Rated Voltage AC
400 V
Min-Max operating voltage AC
12-250/440 V
Frequency
50/60 Hz
Rated Voltage DC
- V
Short circuit capacity EN60947-2 Icu at 400V
6 kA
Service breaking capacity Ics (%Icu)
75%
Standard connection terminals
1…35 mm²
Isolator application according to EN 60947-2
NO
Working temperature
-25/+55 °C
Storage temperature
-55/+55 °C
Approvals
VDE, IMQ
Calibration Temperature (°C)
30
Current limitation class
3
Mounting
any (except upside down)
State
On sale
Brand
AEG
