Series E90
MCB AEG Elfa E90E 1+N B 32A 4,5kA
E91EB32N
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
32 A
Number of Poles
1+N
Rated Breaking Capacity
4,5 kA
Characteristic
B (3 - 5 In)
Standard
EN 60898
Number of modules
2
Power loss
6,144 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
12-250 V
Frequency
50/60 Hz
Rated Voltage DC
- V
Short circuit capacity EN60947-2 Icu at 400V
-- kA
Service breaking capacity Ics (%Icu)
75%
Standard connection terminals
1…35 mm²
Isolator application according to EN 60947-2
NO
Working temperature
-25/+55 °C
Storage temperature
-55/+55 °C
Approvals
VDE
Calibration Temperature (°C)
30
Current limitation class
3
Mounting
any (except upside down)
State
Phased out
