Distribution panelboards up to 144/192 modules
SURFACE DISTR. CABINET GV T.DOOR 144 MOD EMPTY
GV4PT-144
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
wall mounting with door IP40
Modules Capacity
144
Door
glass
Version
Empty, without panels
Protection degree
IP40
placing
wall mounting
Rated Width
670 mm
Rated Height
1310 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
to be set with 150mm or 200mm lids
maximum quantity of modules
192
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK09
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
170
Operation temperature (°C)
-25/+40
Standard
EN 61439
