Technical Specifications
Type
wall mounting with door IP65
Modules Capacity
72
Door
glass
Version
Empty, without panels
Protection degree
IP65
placing
wall mounting
Rated Width
670 mm
Rated Height
710 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
to be set with 150mm or 200mm lids
maximum quantity of modules
96
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK09
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
111
Operation temperature (°C)
-25/+40
Standard
EN 61439
