Distribution panelboards up to 144/192 modules
COMPL. SURFACE DISTR.CAB. GVK IP65 T.DOOR 120M
GVK5PT-120
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
wall mounting with door IP65
Modules Capacity
120
Door
glass
Version
With panels
Protection degree
IP65
placing
wall mounting
Rated Width
670 mm
Rated Height
1110 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
5 height 200mm
maximum quantity of modules
168
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK09
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
144
Operation temperature (°C)
-25/+40
Standard
EN 61439
Brand
SCHALT
