Distribution panelboards up to 144/192 modules
COMPL. SURFACE DISTR.CAB. GVK IP65 O.DOOR 144M
GVK5PC-144
ARMADIO DA PARETE IN METALLO CON PORTA CIECA, GRADO DI PROTEZIONE IP65, COMPLETO DI PANNELLI MODULARI 24 MODULI E GUIDE DIN, COLORE BIANCO RAL9003, TENSIONE DI IMPIEGO FINO A 1000VAC/1500VDC, RESISTENZA AGLI URTI IK10, TEMPERATURA DI FUNZIONAMENTO -25/+40°C, CONFORME ALLA NORMA EN 61439
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
wall mounting with door IP65
Modules Capacity
144
Door
Plain
Version
With panels
Protection degree
IP65
placing
wall mounting
Rated Width
670 mm
Rated Height
1310 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
6 height 200mm
maximum quantity of modules
192
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK10
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
158
Operation temperature (°C)
-25/+40
Standard
EN 61439
Brand
SCHALT
