Distribution panelboards up to 144/192 modules
COMPL. SURFACE DISTR.CAB. GVK IP40 T.DOOR 48M
GVK4PT-48
ARMADIO DA PARETE IN METALLO CON PORTA VETRO, GRADO DI PROTEZIONE IP40, COMPLETO DI PANNELLI MODULARI 24 MODULI E GUIDE DIN, COLORE BIANCO RAL9003, TENSIONE DI IMPIEGO FINO A 1000VAC/1500VDC, RESISTENZA AGLI URTI IK09, TEMPERATURA DI FUNZIONAMENTO -25/+40°C, CONFORME ALLA NORMA EN 61439
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
wall mounting with door IP40
Modules Capacity
48
Door
glass
Version
With panels
Protection degree
IP40
placing
wall mounting
Rated Width
670 mm
Rated Height
510 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
2
maximum quantity of modules
72
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK09
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
108
Operation temperature (°C)
-25/+40
Standard
EN 61439
Brand
SCHALT
