Distribution panelboards up to 144/192 modules
COMPL. SURFACE DISTR. CAB. GVK IP40 O.DOOR 72M
GVK4PC-72
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
wall mounting with door IP40
Modules Capacity
72
Door
Plain
Version
With panels
Protection degree
IP40
placing
wall mounting
Rated Width
670 mm
Rated Height
710 mm
Rated Depth
212 mm
Modules for each row
24
modular rows
3
maximum quantity of modules
96
Rated Current (A)
630 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK10
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
116
Operation temperature (°C)
-25/+40
Standard
EN 61439
Brand
SCHALT
