Distribution panelboards up to 144/192 modules
COMPL. FLUSH FIT DISTR.CAB. GVK IP40 O.DOOR 48M
GVK4IC-48
ARMADIO DA INCASSO IN METALLO CON PORTA CIECA, GRADO DI PROTEZIONE IP40, COMPLETO DI PANNELLI MODULARI 24 MODULI E GUIDE DIN, COLORE BIANCO RAL9003, TENSIONE DI IMPIEGO FINO A 1000VAC/1500VDC, RESISTENZA AGLI URTI IK10, TEMPERATURA DI FUNZIONAMENTO -25/+40°C, CONFORME ALLA NORMA EN 61439
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
flush mounting with door IP40
Modules Capacity
48
Door
Plain
Version
With panels
Protection degree
IP40
placing
flush mounting
Rated Width
737 mm
Rated Height
597 mm
Rated Depth
120 mm
Modules for each row
24
modular rows
2
maximum quantity of modules
72
Rated Current (A)
250 A
Rated Operational Voltage Ue (V)
1000 AC / 1500 DC
Short time current Icw x 1s (kA)
20
Impact resistance
IK10
Body
metal
Colour
White RAL 9003
Maximum heating dissipation (W)
102
Operation temperature (°C)
-25/+40
Standard
EN 61439
Brand
SCHALT
