Elfa NEXT ESD
MAIN SWITCH AEG ESD 3P 100A 3M
ESD30100
SEZIONATORE MODULARE AEG ESD, 3 POLI 3 MODULI, CORRENTE NOMINALE 100A, POTENZA DISSIPATA 8,4W, TENSIONE NOMINALE 415VAC, CATEGORIA D'IMPIEGO AC-22A DC-21A, FREQUENZA 50/60Hz, TEMPERATURA D'IMPIEGO -25/+55°C, TEMPERATURA DI STOCCAGGIO -40/+70°C
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
100 A
Number of Poles
3
Standard
EN 60947-3, VDE 0632 Part 101
Number of modules
3
Power loss
8,4 W
Rated Voltage AC
415 V
Rated Voltage DC
-- V
Isolator application according to EN 60947-3
YES
Category of use
AC-22A, DC-21A
Frequency
50/60 Hz
Mechanical life
20.000 operations
Working temperature
-25/+55 °C
Storage temperature
-40/+70 °C
Standard connection terminals
50 mm²
Mounting
any
Approvals
VDE, KEMA
Brand
AEG
