DC Disconnectors
SEZIONATORE FOTOVOLTAICO SCHALT 2P 20A/1000VDC e 12A/1100VDC
DCLZ220
Sezionatore SCHALT, serie DCLZ, 2 poli, 2,5 moduli, corrente nominale 20A, tensione di impiego max 1100VDC, tensione di isolamento Ui 1500V.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
20A/12A A
Number of modules
2,5
Number of Poles
2
Max operating voltage DC (V)
1100
Rated insulation voltage Ui (V)
1500
Standard connection terminals
2x6 flexible wire, 1x16 fork type mm²
Torque
1,5 Nm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
Mounting
On DIN rail
Brand
SCHALT
Megiston
