ABS Wall-mounting cabinets IP54/IP65

IP65 ABS CABINET 400x600x200 OPAQUE DOOR

SBA642

CASSA IN ABS A DOPPIO ISOLAMENTO IK08 PORTA CIECA GRADO DI PROTEZIONE IP54 PROVA DEL FILO INCANDESCENTE FINO A 650 GRADI TENSIONE NOMINALE FINO A 1000VAC 1500VDC COLORE GRIGIO RAL 7035

+

Downloads and Resources

Download informative and technical materials to learn more about the features of our products.

Click here for download: Product data sheet

Technical Specifications

Type

400x600

Door

Plain

placing

wall mounting

Protection degree

IP54

Material

ABS alogen free

Insulation class

II

Impact resistance

IK08

Temperature resistance

650° C glow wire test

Rated Operational Voltage Ue (V)

Up to 1000V AC / 1500V DC

Rated Width

400 mm

Rated Height

600 mm

Rated Depth

200 mm

Working temperature

-35/+65 °C

Colour

Grey RAL 7035

Standard

EN 62208

Approvals

CE, RoHS
