ABS Wall-mounting cabinets IP54/IP65
IP65 ABS CABINET 300x400x170 OPAQUE DOOR
SBA431
CASSA IN ABS A DOPPIO ISOLAMENTO IK08 PORTA CIECA GRADO DI PROTEZIONE IP54 PROVA DEL FILO INCANDESCENTE FINO A 650 GRADI TENSIONE NOMINALE FINO A 1000VAC 1500VDC COLORE GRIGIO RAL 7035
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
300x400
Door
Plain
placing
wall mounting
Protection degree
IP54
Material
ABS alogen free
Insulation class
II
Impact resistance
IK08
Temperature resistance
650° C glow wire test
Rated Operational Voltage Ue (V)
Up to 1000V AC / 1500V DC
Rated Width
300 mm
Rated Height
400 mm
Rated Depth
170 mm
Working temperature
-35/+65 °C
Colour
Grey RAL 7035
Standard
EN 62208
Approvals
CE, RoHS
